Prefabricated Modular Containerized Substation

Get Latest Price

Payment Type:

L/C,T/T

Incoterm:

FOB,CFR,CIF

Min. Order:

1 Set/Sets

Delivery Time:

30 Days

Transportation:

Ocean,Land,Air

Contact Now

Chat Now

Product Description

Product Attributes
Product Feature
Product description

< >

Overview

Product Attributes

Model No.: ANSI/IEEE Pad-mount Series

Brand: HENGFENGYOU

Application: US/LATAM Residential Grids, Data Centers, Commercial Buildings

Phase: Three

Rated Voltage: 4.16kV, 12.47kV, 13.2kV, 13.8kV, 24.9kV, 34.5kV

Rated current:

Frequency: 50Hz

Degree of protection: IP54 / IP55 / IP65

Standard: IEC60076

Certificate: CB CCC SABS

Shell Material: Steel

Origin: China

Packaging: Plywood

Delivery Time: 30 Days

Product Feature

Product description

Product Overview
Our Prefabricated Modular Containerized Substation (also known as a Smart Modular Substation) represents the future of power infrastructure construction. By deeply integrating and commissioning high-voltage switchgear, transformers, medium-voltage switchgear, distribution automation systems, and auxiliary equipment within the factory, we transform traditional substation "engineering projects" into rapidly deliverable "industrial products.". This "plug-and-play" model not only significantly shortens construction cycles but also demonstrates incomparable advantages in footprint, environmental adaptability, and overall cost.
Core Advantages
Factory Pre-integration for Rapid Delivery
All internal equipment completes installation, wiring, and joint commissioning within the factory.
On-site work requires only simple foundation positioning and external cable connection, shortening the construction cycle by more than 70% compared to traditional civil-engineered substations.
Extremely Compact and Space-saving
Utilizing a highly integrated design, the footprint can be reduced by 60%-80% compared to traditional open-type substations.
It is particularly suitable for urban centers, industrial parks, mines, and other space-constrained areas.
Fully Enclosed Design for All-weather Operation
The enclosure is constructed from special steel or corrosion-resistant aluminum alloy, complemented by marine-grade anti-corrosion coating.
An integrated smart HVAC system ensures stable operation in extreme heat (+50°C), extreme cold (-40°C), high salt spray, or heavy dust environments.
Intelligent Monitoring for Unattended Operation
Integrated with advanced digital monitoring terminals, it supports real-time online status monitoring, remote diagnosis, and intelligent warnings.
This perfectly adapts to digital grids and smart energy management.
Green, Low-carbon, and Recyclable
It significantly reduces noise, dust, and construction waste from on-site civil works.
When a project migrates or expands, the entire containerized substation can be moved as a whole, realizing asset reuse.
Internal Units
HV Section (High Voltage): Flexible configuration of SF6 circuit breakers or compact GIS switchgear based on customer requirements.
Transformer Section: Compatible with high-efficiency oil-immersed power transformers or fully insulated dry-type transformers.
MV Section (Medium Voltage): Integrated high-performance gas-insulated switchgear (C-GIS) or metal-enclosed withdrawable switchgear.
Control and Protection Unit: Includes UPS redundant power supply, relay protection, communication modules, and fire alarm systems.
Technical Specification

Items	Technical Indicators
Rated Voltage Level	10kV / 35kV / 66kV / 110kV
Rated Capacity Range	1000kVA - 63000kVA
Enclosure Protection Class	IP54 / IP55
Annual Leakage Rate (SF6 Unit)	≤ 0.1%
Ambient Adaptability Temp.	-45°C to +55°C
Seismic Intensity	Level 8 and above

Applications
Renewable Energy Generation: Centralized PV power plants and wind farm step-up stations.
Industrial and Infrastructure: Rapid power supply for large factories, mining areas, and data centers.
Grid Expansion: Rapid on-site capacity expansion and renovation of substations in old urban areas.
Temporary and Mobile Power: Large event support, disaster relief, and emergency power supply needs.
